LED VacPort | InterVac A-901-X Central Vacuum Inlet

LED VacPort Sweep Inlet with Coupling Attached

The InterVac A-901-X LED VacPort is a sweep inlet that sits at floor level in a toe kick or baseboard. You open the door with your toe, the central vacuum starts, and you sweep dirt straight into the port. It travels down the pipe to the vacuum’s dust bag. No hose plugs into a VacPort; your cleaning hose goes into an inlet valve.

When does the LED come on? The LED comes on when you open the VacPort door and the vacuum starts. It lights the floor in front of the port so you can see fine dust and hair, and it confirms the vacuum is running.

What makes the A-901-X different The A-901-X comes with a P-30 pipe-to-pipe coupling attached to the back of the port, so it glues straight onto 2″ central vacuum pipe. It ships in a poly bag without the trim plate or retail box. If you are replacing an old dust pan or need to cover a larger opening, choose the A-900-X, which includes the trim plate.

Key Features

• LED comes on when the door opens and the vacuum runs
• P-30 coupling attached for 2″ central vacuum pipe
• Door held open by two magnets; no springs
• PC/ABS housing, door and bridge
• Works on 24V AC or DC low-voltage central vacuum circuits
• Available in Ebony black (-E) or White (-W)

Technical Information

• Part number: A-901-X (-E Ebony black, -W White)
• Type: LED VacPort sweep inlet
• Wall opening: 6-1/8″ wide x 2-1/2″ high, flush with the floor
• In the package: VacPort with LED, P-30 coupling attached, mounting screws
• Not included: trim plate, retail box (see A-900-X)
• Manual: M-20 VacPort manual
• Warranty: 2 years
